| Product characteristics |
| Electrical design |
PNP |
| Output function |
normally closed |
| Sensing range [mm] |
12 |
| Housing |
threaded type |
| Dimensions [mm] |
M18 x 1 / L = 50 |
| Application |
| Special feature |
Gold-plated contacts; Increased sensing range |
| Application |
Industrial applications / factory automation |
| Electrical data |
| Operating voltage [V] |
10…30 DC |
| Current consumption [mA] |
< 10 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Outputs |
| Electrical design |
PNP |
| Output function |
normally closed |
| Max. voltage drop switching output DC [V] |
2.5 |
| Permanent current rating of switching output DC [mA] |
100 |
| Switching frequency DC [Hz] |
300 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Detection zone |
| Sensing range [mm] |
12 |
| Real sensing range Sr [mm] |
12 ± 10 % |
| Operating distance [mm] |
0…9.72 |
| Increased sensing range |
yes |
| Accuracy / deviations |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3 |
| Hysteresis [% of Sr] |
3…15 |
| Switch point drift [% of Sr] |
-10…10 |
| Operating conditions |
| Ambient temperature [°C] |
-25…70 |
| Protection |
IP 67 |
| Mechanical data |
| Weight [K40] |
41.6 |
| Housing |
threaded type |
| Mounting |
non-flush mountable |
| Dimensions [mm] |
M18 x 1 / L = 50 |
| Thread designation |
M18 x 1 |
| Materials |
brass white bronze coated; sensing face: PBT orange; LED window: PEI; lock nuts: brass white bronze coated |
| Displays / operating elements |
| Display |
| switching status |
4 x LED, yellow |
|
| Accessories |
| Accessories (supplied) |
|
| Remarks |
| Pack quantity |
1 pcs. |
| Electrical connection – plug |
| Connection |
Connector: 1 x M12; Contacts: gold-plated |
