EP7047-1032 | EtherCAT Box, 1-channel motion interface, stepper motor, 48 V DC, 5 A, M12, with incremental encoder
SKU: EP7047-1032
Hãng sản xuất: Beckhoff
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
| Technical data | EP7047-1032 |
|---|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, shielded, screw type |
| Number of channels | 1 |
| Number of outputs | 1 x stepper motor, 1 x motor brake |
| Number of inputs | 2 x end position, 1 x feedback |
| Connection method | direct motor connection + feedback |
| Load type | 2-phase stepper motor (uni-/bipolar) |
| Nominal voltage | 24 V DC |
| Supply voltage power | 8…48 V DC (external) |
| Output current | max. 5.0 A |
| Distributed clocks | yes |
| Step frequency | configurable up to 16,000 full steps/s |
| Step pattern | 64-fold micro stepping |
| Current controller frequency | approx. 30 kHz |
| Diagnostics LED | error phase A and B, loss of step/stagnation, power, enable |
| Resolution | approx. 5000 positions in typ. applications (per revolution) |
| Encoder connection | A, B, C, gate/latch |
| Encoder operating voltage | 24 V DC, typ. 20 mA |
| Electrical isolation | 500 V |
| Current consumption from US | 120 mA |
| Special features | travel distance control, encoder input, vector control |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL in preparation |
