Quạt tản nhiệt EBMPapst G3G190-RD45-03

Type G3G190-RD45-03 Motor M3G055-CF Nominal voltage VAC 230 Nominal voltage range VAC 200 .. 240 Weight 2.1 kg Fan size 190 mm Rotor surface Thick-film passivated Impeller material PA plastic Housing material PP plastic Number of blades 7 Direction of rotation Clockwise, viewed toward rotor Degree of protection IP54; installation- and position-dependent Technical features - Output 10 VDC, max. 10 mA - Tach output - Power limiter - Motor current limitation - Soft start - Control input 0-10 VDC / PWM - Control interface with SELV potential safely disconnected from the mains - Overvoltage detection - Thermal overload protection for electronics/motor - Line undervoltage detection
